PET Bottle Blow Molding Machine

Description

Usage:

PET bottle blow molding machine is a high speed automatic PET blower. Because it is with the most advanced bottle blowing technology at present.

The advantages are speedy, stable, simple, general purposed and environmental safe.

It is mainly applicable in blow molding PET bottle for water, beverage, juice, etc. And the machine yields abundantly with high efficiency.

Main parameters:

speed: 2000-24000 bottle per hour 500ml

suitable bottle volume: 200-2000ml

Main features:

1.high-efficient preform supply system:

It use fully-automatic preform-unscrambled and preform-loading structure. And the preform-unscrambled and preform-loading work faster and high-efficient.  Also it improve the stability of the whole machine running process. Besides there is a sensor installed in the preform down-track. When the preform track lack of preform, the hopper will deliver the preform into the preform-unscrambled system automatically.

2.Servo preform-divided system:

we use servo motor to divide the preform equidistant. And you can adjust the stroke and speed of servo motor through the HMI. Also all complicated process are digitization, safe, fast and accurate. Comparing with the traditional server-ways preform-divided, cylinder type preform-divided etc，the servo motor control one-way preform-divided, speed is more faster and position is more accurate.

3.Intelligent heating system:

Infrared lamps heat preform, it make the preform stretching more equably and higher transparency. With the help of imported reflective mirror aluminum plate, the heat energy of lamps are full advantage of: heating time is shorter ; lower power consumption and improving the production capacity. You can adjust the temperature of each lamp of every layer up and down. Intelligent ventilation system keeps the oven temperature inside constantly.

4.Servo mold-clamping system:

The servo motor drive mold-clamping system. And the servo motor clamped the molds and bottom mold synchronously through . High-pressure mold-locked by the high-pressure pressurized plates behind the mold framework which can reduce visibility of the bottle clamping line effectively and ensure the bottle quality. Drawer type mold structure design, easy mold exchange, skillful engineer can finish the mold exchange in half an hour.

5.Servo stretching system:

The servo motor drives the gear rack to stretching. With our developed photoelectric and mechanical limits these two double security, the stretching rods can not hit the bottom mold. The pre-blowing and 2nd blowing cycle time can be adjusted individually in the HMI according to different preform and bottle design. The stretching rods can be adjusted automatically, high flexibility.

6.HMI operation system:

Our blow molders are high intelligence, easy operation. And We use Chinese-English language color touch screen. Then it is with perfect monitoring sense setting, troubleshooting display, auto calculating report, memory store etc. function. so, you can control the machine production situation all the time.
